A variety of creative and functional designs can be realized with the insulating glass OKATHERM without inserts. A broad palette of different types of glass, coatings and build-ups offer protection and supply functions for façade and roof and meet the specific functional requirements of architects and planners for each project. The combination of OKATHERM insulating glass with other OKALUX solutions will also ensure a uniform façade appearance.
High Degree of Functionality and Variety of Design
- Most of the technical values and functions are variable and can be adapted to the specific requirements:
- Overall energy transmittance (TSET)
- Heat transmittance coefficient (Ug)
- Light transmission (Tv)
- Light reflection (Rv)
- Noise insulation (Rw)
- Color rendering
- UV irradiance value
- Fire protection
- Burglary protection and safety barrier
- Glass sealant
- Broad spectrum of applicable types of glass
- Constructional open space design through glass protrusions, models, curved glass or integrated mounting systems
- 4-pane build-ups are possible depending on the technical requirements
- The insert-free cavity allows for both very large and especially narrow and light pane build-ups
- Can be combined with all other OKALUX products for a uniform façade appearance
Sustainability
- Daylight input reduces requirements for artificial light
- Reduction of cooling loads in summer, solar gains in winter
- Fully recyclable
User Comfort
- The use of daylight and a comfortable room climate create a comfortable atmosphere
In the standard structure, the visible width of the perimeter seal is 12 mm. Glass-specific static loads may make a reinforced version necessary. On request we can offer various special structures, such as
- stepped edges, if required with sheet metal applied to eave or glass Joint
- stainless steel spacers
- U-profiles in the perimeter seal to hold the glass with claws
- silicone-compatible secondary seals
- glass types for structural sealant glazing
- Maximum dimensions: 6,000 mm x 3,210 mm, larger sizes available upon request
Insulating glass Units with a total weight of up to 1,000 kg - A variety of structural and function designs can be created using OKATHERM functional insulating glass. A broad range of glass types, coatings and structures offer protection and supply functions for the facade or roof:
- Overall energy transmittance (TSET)
- Heat transmittance coefficient (Ug)
- Light transmission (Tv)
- Light reflection (Rv)
- Noise insulation (Rw)
- Color rendering
- UV irradiance value
- Fire protection
- Burglary protection and safety barrier
- Glass sealant
- Ug-values achieved with common OKATHERM build-ups; in a 2-pane build-up up to 1.0 W/(m²K), in a 3-pane build-up up to 0.5 W/(m²K). The achievable g-value and light transmission depend on the product variant chosen, which in essence involves the coating, glass types and thicknesses.
