OKALUX EVO

Optical illusion of depth through visible capillary structure

OKALUX EVO light-diffusing insulating glass offers numerous advantages: The capillary slab in the cavity allows for an even and shadow-free illumination with daylight deep into the room. The sun and glare-protection are very good, the heat insulation excellent and the transmission values individually adjustable to the requirements.

The fiber glass mat located only between the two capillary slabs is visible from both sides of the OKALUX EVO and creates an attractive lively surface.

©Trevor Palin for Waagner-Biro — Wellcome Trust - Wellcome Genome Campus Conference Centre - OKALUX EVO

High Functionality

Optimal, even illumination of the room, without hard shadows
Effective sun and glare protection
High light transmission, light entry can be adjusted individually
High colour rendering
Good heat and sound insulation
Protection from UV rays
Bird-friendly solution
Fire protection according to requirements

Sustainability

Daylight entry reduces amount of artificial light required
Reduction of cooling loads in summer
Fully recyclable
Long-Lasting, maintenance-free and easy to clean

Attractive Aesthetics

Attractive appearance
Vivid surface with depth effect
Capillary inserts can be printed with colour and décor

User Comfort

Comfortable daylight atmosphere
Effective privacy protection
Reduced amount of solar input into the building

OKALUX EVO – double glazing build-up – vertical glazing — Build-up – vertical glazing

OKALUX EVO – double glazing build-up – horizontal glazing — Build up – horizontal glazing

Maximum dimensions: 2,000 mm x 6,000 mm, larger sizes available upon request
All technical values, such as light transmission, TSET and Ug-values can be varied by using other constructions and glass types.
The Ug-value for the various versions is dependent, among other things, on:
- the thickness of the KAPIPANE insert: 16 - 40 mm (2-pane make-up)
- the functional coating on surface #2 (3-pane make-up)
- the filling gas in the cavity between panes (Air/Argon/Krypton)
